VxRail V7.x log collection failed

Recently I ran into a problem when I needed to generate a VxRail V7.x support log bundle. The log collection failed after I went to the VxRail log section.

Cluster > Configure > VxRail > Troubleshoot > Create

After hitting the Create button I selected the required data. In my case the VxRail Manager data was enough.

When start to Generate the log bundle nothing happened. The Create button was greyed out for a few minutes and no log bundle was generated.

Solution:

  • Take a snapshot of the VxRail Manager vm
  • Open a ssh session to the VxRail manager
  • Login with mystic, switch to root
  • Cd /tmp/mystic/dc
  • Look for old log bundles for example VxRail_Support_Bundle_12d4235c-1458-d47f-e68b-a3221bca3bc3_2022-01-01_12_00_00.zip
  • Delete all old log bundles in /tmp/mystic/dc
  • Systemctl restart runjars
  • Systemctl restart vmware-marvin
  • Wait about 5-10 min.
  • Try again collecting VxRail manager logs

Now the VxRail Support log bundle was successfully generated.

If you are not familiar enough you can always open a Dell Support request. They will then help you further.

VMware vRealize Log Insight alerts in Microsoft Teams

Recently, We missed an alert notification that had been generated in VMware vRealize Log Insight (vRLI) outside of office hours. This had caused a disruption that we could have avoided if we had been informed in time. The alert notifcation had been sent via email but email is not always accessed outside of business hours. Which I can well understand. In this blog, I will explain what I have come up with to notice these types of alerts earlier.

Use Case – Increase the ability to notice prio 1 alerts outside of office hours with the available technical resources.

Goal – In addition to the standard vRLI alerts, we also want to have the option available to receive alerts through Microsoft (MS) Teams.

Solution – Use vRLI Webhook to send alerts to MS Teams

Setup – In order to have vRLI alerts sent to MS Teams, we need to set up two things.

  1. Setup a MS Teams Connector to receive alerts
  2. Setup the vRLI Webhook configuration to push alerts

Setup a MS Teams Connector to receive alerts

First, decide in which Teams Channel you want to receive the vRLI Alerts or add a new Teams Channel. I have created a new Channel called VRMware VMware Alerts.

Click on the 3 dots on the right side and select Connectors.

Select Configure Incoming Webhook.

Provide a friendly name, upload an image and create the connector.

After creation copy the url to the clipboard. We need this URL later to configure the vRLI Webhook.

Before we move on to vRLI we need to enable the channel notifications. Click once again on the 3 dots on the right side and select Channel notifications > All activity.

Setup the vRLI Webhook configuration to push alerts

Go to the Administration section and open Configuration > Webhook > New Webhook. Choose a name. From the Endpoint drop down menu select Custom. Copy the Webhook URL that was copied from MS Teams connector. From the Content Type drop down menu select JSON and from the Action drop down menu select POST. The Webhook Payload will be described under the picture.

Webload Payload

The Webload Payload was the hardest part to configure. Thanks to my colleague Roger who has figured out how the Webhook Payload layout should look like.

As far as I know, from vRLI Webhook only clear text can be used to send notifications to MS Teams. It’s possible to use one or more parameters in the script. For an overview of the parameters see the picture above here. Because the notictions are send in clear text it’s not possible to use all parameters. In our case not a problem because MS Teams is not used to replace monitoring software. It is just an additional option to be informed in a timely manner.

I wouldn’t go indepth how we found out the layout of the Webhook Payload code. That’s why I’m only sharing the code with you, so you can start testing for yourself.

{
   "type":"message",
   "attachments":[
      {
         "contentType":"application/vnd.microsoft.card.adaptive",
         "contentUrl":null,
         "content":{
            "$schema":"http://adaptivecards.io/schemas/adaptive-card.json",
            "type":"AdaptiveCard",
            "version":"1.2",
            "body":[
                {
                "type": "TextBlock",
                "text": "${AlertName}",
				"weight": "bolder",
                "wrap": true
                }
            ]
         }
      }
   ]
}

After completing the Webhook configuration you may want test the Webhook configartion. Press the Send Test button.

Finally Save the Webhook configuration.

Open the MS Teams Channel where the connector was created earlier. You should see here the Test Alert.

The last part is sending a notification to MS Teams when a ESXi host have entered Maintenance Mode.

I have created an vRLI alert with the name “TEST VRMware VRLI Alert: vSphere Host entered Maintenance in vCenter“.

I have decided that I would like to be notified by both email and MS Teams. This can be set under the Trigger Conditions.

If everything is configured correctly we should receive the Send Test Alert Results after sending a test alert.

Save the Alert. Now we are ready for the final test. I put a ESXi host in maintenance mode and we should receive within 5 minutes a MS Teams notification. It works!

I hope this blog post will help you configure vRLI to send notifications to MS Teams. Please remember that MS Teams is not a monitoring tool. So be selective with the alerts you forward. I have chosen to only forward alerts that I know need to be acted on as soon as possible.

Replacing the VxRail Manager SSL Certificate failed

Cause:
Replacing the VxRail Manager SSL Certificate through the Certificate Management Gui ended up with an error.

I was used to replacing the VxRail certificate using the cli. This was the preferred way somewhere up to version VxRail 4.7.x. All preparations for using the gui are the same as when replacing the certificate through the cli:

  1. Config OpenSSL.conf with the required information
  2. Create RSA key
  3. Creare CSR file
  4. Request a Certificate signed by your CA
  5. Download Certificate CA chain

The certificate and CA certificate chain must still be in PEM format.

So I start with a snapshot of the VxRail manager and copied the VxRail certificate, RSA key, certificate chain and entered a password in the gui. After pressing the Update button I received the following error.

Solution:
I will briefly tell you what went wrong. As told earlier, I used the same way to create the certifcates as I did when using the cli.

The error was caused by the certificate CA chain. After downloading the certificate CA chain file, the certificates are listed from top to bottom. The Root CA was at the bottom. This is order has always worked when replacing the VxRail manager certificate using the cli.

I was led to the solution after reading the certificate chain content information twice, see the screenshot above here. I assumed that the certificate format was causing the issue. There is also information about the certificate format next to the information about the order of the CA certificates in the chain file. I changed the order of the CA certificates in chain file with the Root CA on top.

At the next try I copied again the VxRail certificate, RSA key and certificate chain and entered a password in the gui. After pressing the Update button I received a notification that the VxRail Manager certificate is successful replaced. It takes about 5 minutes, before the VxRail manager is back online.

During this 5 minutes the VxRail SSL Thumbprint in the cluster in vCenter will be updated and services will be restarted. You can see the VxRail SSL Thumbrint on the cluster summary page in vCenter.

This auto replacement of the VxRail SSL Thumbprint is an enhancement compared to the old way when the certificate was replaced using the cli. The VxRail SSL Thumbprint then had to be manually read and copied from the VxRail manager to the cluster custom attribute in vCenter.

Return to the VxRail System info page after 5 minutes. You should now see the VxRail information.

Done.

VMware Vrealize Log Insight upgrade from CLI

Did you know that you can also upgrade vReaze Log Insight from the CLI?

  • Upload the .PAK file to /tmp on the Log Insight appliance
  • Open 2 ssh sessions to the Log Insight appliance
  • Run the following Python script: /usr/lib/loginsight/application/sbin/loginsight-pak-upgrade.py /tmp/VMware-vRealize-Log-Insight-8.6.0-18703301.pak
  • Open the second ssh session to follow the progress in realtime in the upgrade log.
    tail -f /var/log/loginsight/upgrade.log

When the upgrade is finished the ssh sessions will be ended while the Log Insight aplliance is rebooting.

Done!

Configure VxRail Manager forward logs to vRealize Log Insight

This post is written by Steve Hagerty. Since I find this a very valuable blog, I have decided reblogging this article. The original article can be found here.

This is a short post to explain how to configure syslog forwarding from VxRail Manager to vRealize Log Insight.

Depending on the deployment scenario, VxRail may or may not be automatically configured to forward all of its associated logs to vRealize Log Insight. For example with VCF on VxRail, this configuration is automated for all VxRail components, while in other situations this may need to be configured manually.

There are three primary VxRail components to configure:

  • VxRail Manager
  • vCenter Server
  • ESXi Hosts

… with the iDRAC of each VxRail node also being an option.

The configuration of the VxRail vCenter Server in vRLI can also incorporate configuring the log forwarding from the associated ESXi hosts if selected, as shown below:

This is all managed under the built-in vSphere integrations for vRLI. What remains then, if required, is to configure VxRail Manager to forward its logs (marvin.log) to vRLI.

As described in KB504644 VxRail: How to configure a new syslog server , SSH to VxRail Manager as mystic user and switch user to root user, before editing the /etc/rsyslog.conf file with the following additional entries:

#
# Marvin log to loginsight
#
$ModLoad imfile
$InputFileName /var/log/vmware/marvin/tomcat/logs/marvin.log
$InputFileTag VxRail
$InputFileStateFile VxRail-Log-State
$InputRunFileMonitor
*.* @<customer remote server ip:514>

Advertisementshttps://c0.pubmine.com/sf/0.0.3/html/safeframe.htmlREPORT THIS ADPRIVACY

Ideally you should use the Log Insight load balancer IP as the target for the <customer remote server ip> (syslog/vRLI server IP), where 514 is the udp port.

Update 31/03/2021: In additional, to the above, the /var/log/mystic/connectors-cluster.log and the /var/log/mystic/connectors-esrs.log can be added to this list, simply by adding them as additional $InputFileName line items, as shown below:

Restart the syslog service using command on VxRail Manager: service rsyslog restart (or reboot the VxRail Manager VM if required).

We can then confirm that the vRLI system is receiving the forwarded logs from our VxRail Manager (vcf2mgmtvxrmgr) in the vRLI UI under Administration > Hosts

Advertisementshttps://c0.pubmine.com/sf/0.0.3/html/safeframe.htmlREPORT THIS ADPRIVACY

On the Interactive Analytics tab we can filter for the VxRail Manager hostname of vcf2mgmtvxrmgr in order to get more detail on each event received since the log forwarding was configured.

The events received from the VxRail Manager source will automatically be included in the General vRLI Dashboard, as shown below

It is also possible to create your own custom VxRail dashboard in vRLI if required. A new (VxRail) dashboard can be created under My Dashboards, where new and existing widgets can be copied and modified as required.

For completeness, if a customer requires the iDRAC logs of the VxRail nodes to be forwarded to vRLI also, then please take a look at this post which covers the required steps, leveraging the Dell iDRAC Content Pack for vRLI, installable directly from the vRLI Content Pack Marketplace, as shown below:

Advertisementshttps://c0.pubmine.com/sf/0.0.3/html/safeframe.htmlREPORT THIS ADPRIVACY

And that’s about it really, I hope that helps!

Steve

Get notificated when vSAN Force Provisioning is enabled and applied to a vm

Recently I was asked if it is possible to receive an email notification if a vSAN storage policy with Force Provisioning enabled is applied to a vm. In this blogpost I want to show that this is possible.

Use Case – An administrator wants apply an vSAN storage policy with Force Provisioning enabled to virtual machines beacause of a possible shortage of vSAN storage capacity. In my opinion not a very good idea in a production environment!

Goal – Get an email notification when a vSAN storage policy with Force Provisioning enabled is applied to an vm. There is also the wish to make this visable in a dashboard.

Solution – With a bit of reverse engineering and vRealize Log Insight (vRLI) it’s possible to achieve this.

Setup lab – VMware vSphere 7.0 Update 3a vSAN cluster and vRLI 8.6.

The first step is create a storage policy with Force Provisioning enabled. We name this policy “FP VM Storage Policy”

We need to apply the new storage policy “FP VM Storage Policy” to our test vm “sbpm01”

The policy is successful applied to the vm “sbpm01”.

Now we need some reverse engineering because it’s not possible to grep the name of the storage policy in vRLI. We move to the sbpm01 events in vCenter.

Note the following two details:

  1. Event Type ID: com.vmware.pbm.profile.associate
  2. Associated storage policy: 98df0443-5244-49af-9069-ad9fdbfedb52

This is the information we need to created a new filter in vRLI Interactive Analytics.

Add the associated storage policy id “98df0443-5244-49af-9069-ad9fdbfedb52″ to the text field and add an extra filter (+ ADD FILTER). Choose from the pull down menu “vc_event_type” contains com.vmware.pbm.profile.associate. Choose a time window. In our example I choose “Latest 24 hours of data”. You can also choose here the last hour or last 5 minutes of data. It depends on the time you applied the policy and when you search in vRLI.

In de results above you don’t see the name of the vm with the applied storage policy. In the last image above here you see on the right of Events the Field Table section. Select Field Table. Search for the row with name vc_vm_name. Below here is the vm friendly name displayed of the vm with new applied storage policy.

Finally you want a email notification and a dashboard. I am not going to explain here how to create an email notification and a dashboard. This can be done in vRLI at the same way you normally create notifications and dashboards. Press the icon (1) to create a email notification and press the icon (2) to create a dashboard.

If you want receive an email notification if the vm get another storage policy applied. Then you should create another filter including the following two details.

  1. Event Type ID: com.vmware.pbm.profile.dissociated
  2. Associated storage policy: 98df0443-5244-49af-9069-ad9fdbfedb52

Conclusion:

In this blog post I wanted to demonstrate that it is possible with vRLI to receive an email notification if a vm has a storage policy applied where Force Provisioning is enabled. A disadvantage is that if the vm gets a different storage policy with different settings, this email notification is no longer valid, because the notifications are based on this specific storage policy id.

I have shown that it is works but as far as I believe it is not a solution for a production environment.

VxRail 7.0.300 GA

What’s new in VxRail 7.0.300

VxRail software version 7.0.300 includes VMware ESXi 7.0 Update 3, VMware vSAN 7.0 Update 3 and VMware vCSA 7.0
Update 3a with support for external storage and introduction to satellite nodes.

New features

Operationalize the edge with VxRail satellite nodes:
You can deploy the E660, E660F, and V670F as single VMware vSphere nodes with no VMware vSAN to address VxRail edge deployments that require a smaller footprint. You can configure satellite nodes with an optional PowerEdge RAID controller to add resiliency for local disks. The satellite nodes are managed by a new or existing standard cluster with VMware vSAN running 7.0.300.

Control satellite nodes from a central location:
You can deploy a VxRail Manager VM that can control all satellite nodes from a centralized host management location in VMware vCenter. You can add, remove, and update satellite nodes from one access point using VxRail Manager.

Expanded storage option for VxRail dynamic nodes:
You can deploy VxRail dynamic nodes as part of a PowerFlex 2-layer architecture. Deploy VxRail dynamic nodes cluster as compute only node leveraging PowerFlex storage for hosting the workload VMs.

Protocol support for VxRail dynamic nodes:
NVMe-FC is supported with PowerStore and PowerMax storage arrays that are attached to dynamic nodes.

VMware ESXi 7.0 Update 3, VMware vSAN 7.0 U3, VMware vCSA 7.0 Update 3a support. The major changes for VxRail include:
Support upgrade of the VMware vSAN Witness Host (dedicated) in vLCM as part of the coordinated cluster remediation workflow for VMware vSAN 2-Node and Stretched Clusters.

  1. Stretched Cluster Enhancement to allow the ability to tolerate planned or unplanned downtime of a site and the witness in a stretched cluster deployment.
  2. Nest Fault Domain in a 2-node configuration
  3. Easy VMware vSAN cluster shutdown and start-up
  4. Upgrade note for VxRail with external storage

Source: https://dl.dell.com/content/docu98130

Extracting VxRail code 7.0.2xx failed at 50%

Sometimes you run into an issue that can keep you busy for hours and afterwards the cause remains easy to solve. Recently I ran into such an issue.

There was a minor update that needs to be done. It was a VxRail code upgrade from 7.0.x to 7.0.2xx.

The upgrade was basically like all other upgrades:

  1. Run VxVerify
  2. If there are findings in the results, solve them before starting the upgrade
  3. Upload the desired VxRail target code
  4. Start the upgrade
  5. Done

The results of the vxVerify were fine, no issues detected.

While uploading the target VxRail code everything looks fine but during the extraction of the upgrade bundle it failed at 50%. So I start a retry but the extraction of the upgrade bundle failed again at 50%. At the Cluster level we noticed the following error.

VXR1F4114 ALARM Upload of upgrade composite bundle unsuccessful VxRail Update ran into a problem… Error extracting upgrade bundle 7.0.2xx. Failed to upload bundle. Please refer to log for more details.

I opened a support request by Dell Support and in the meantime I start to examine the lcm-web.log in /var/log/mystic. I found some errors and failures but they did not lead directly to the root cause. There were errors about upgrade bundles couldn’t uploaded but those events were too general. I noticed the VxRail node that was mentioned at last in the log before the extraction failed.

Dell Support was now also working on the case. The support engineer also noted that the VxRail node I suspected was causing the problem.

I won’t go into too much detail, but at some point we checked the status of the “dcism-netmon-watchdog” service on that particular VxRail node.

[root@ESXi03:~] /etc/init.d/dcism-netmon-watchdog status
iSM is active (not running)

I had seen recently the same service status on another VxRail nodes running on code 7.0.x. Restarting the service won’t start the service. So I restarted the VxRail node. After the restart it could take some minutes before the service is restarted. I checked the service again.

[root@ESXi03:~] /etc/init.d/dcism-netmon-watchdog status
iSM is active (running)

Finally we restarted(retry) the VxRail code extraction. Both the VxRail code extraction and VxRail upgrade were successful.

vSAN detected an unrecoverable medium or checksum error

If there is a hardware issue that could cause problems within a vSAN cluster, you want to know as early as possible. Once you know this, you may have time to resolve the issue before business is compromised.

Cause:

I have seen the following error several times in the results of a VxRail VxVerify check, which is performed to identify issues in a VxRail cluster before an update.

Error:

++++++++++++++++++++++

2021-10-08 15:01:00.012 esxi01.vrmware.nl vcenter-server: vSAN detected an unrecoverable medium or checksum error for component AB1234 on disk group DG5678

++++++++++++++++++++++

It could be possible that an underlying hardware device (physical disk) is causing this error. This is why you want to be informed as early as possible if there is an error that can cause an vSAN issue in the near future. This allows you to proactively carry out repair work, without any downtime to business operations.

Resolution:

How do you find out on which physical disk the component resides on? You need to identify the following information (first 3 bullets). The 4th bullet is about the vm which can be possible affected by the issue.

  • VMware Host
  • Diskgroup
  • Disk
  • Virtual Machine where the component belongs to

Let’s start to identify the disk where the component resides:

  1. Write down the component and diskgroup from the error
  2. Ssh to an arbitrary ESXI server in the vSAN cluster. It doesn’t matter what server you choose. Type the following command:
    esxcli vsan debug object list –all > /tmp/objectlist.txt
  3. Transfer /tmp/objectlist.txt to local pc
  4. Open objectlist.txt and search for component AB1234.

Snippet from objectlist.txt:
++++++++++++++++++++++

Configuration:

RAID_5

Component: AB1234

Component State: ACTIVE,  Address Space(B): 39369834496 (36.67GB),  Disk UUID: 52ec6170-5298-7f14-1069-d0d3872b742a,  Disk Name: naa.PD9012:1

Votes: 1,  Capacity Used(B): 39753613312 (37.02GB),  Physical Capacity Used(B): 39359348736 (36.66GB),  Host Name: esxi03.vrmware.nl

Type: vdisk

Path: /vmfs/volumes/vsan:1234567890/vm01.vmdk (Exists)

++++++++++++++++++++++

All the info you need to identify the disk is almost all here, VMware Host, Diskgroup and VM. To indentify the possible affected disk you need to switch to vCenter gui.

Move to Cluster > Host (esxi03.vrmware.local) > Monitor > Performance > Disks > Diskgroup (DG5678) > Whole Group (pull down). Here do you find the disk naa.PD9012

Conclusion:

Now you know that component AB1234 resides on disk naa.PD9012 in diskgroup DG5678 and the component belongs to vm01.vmdk.

I would advise always contact VMware GS for support in any production environment or Dell Support in case of a VxRail cluster. They will provide further support and help you to fix this error.

Hopefully this helps you.

VMware vCLS datastore selection part 2

Last year I wrote an blog post about the VMware vCLS datastore selection. This blog post is one of the most read articles on my website. This does indicate that there is a need to be able to choose a datastore on which the vCLS vms are placed.

Today VMware announced vSphere 7.0 update 3. In this update there is also an improvement on the vCLS datastore selection. It’s now possible to choose the datastore on which the vCLS vms should be located.

In the following video on the VMware vSphere YouTube channel move on to 20 minutes to learn more about the vCLS vms datastore selection improvement.

Another improvement is that the vCLS vms now have a unique identifier. This is useful when you have multiple clusters managed by the same vCenter.

It’s always good to see that a vendor is listening to the customers’ needs to further improve a product.
